The Ducati Panigale family demands components that match its engineering intent. These steering head inserts are offered sold as a set, meaning both the upper and lower cups are supplied together to preserve alignment and handling consistency. Developed and tested by Ducati Corse, the inserts are intended to meet the same quality and fitment standards used in Ducati’s race and development programs. If you’re preparing a track bike or restoring factory geometry, choosing parts that reflect the original specification helps ensure predictable steering response and longevity.
Design intent and application
The inserts are engineered specifically for the Ducati Panigale V2 and V4 superbikes, addressing the steering assembly’s load paths and precision requirements. Steering head insert here refers to the machined cups that sit in the headstock and house the steering stem bearings; they are critical for axial alignment and smooth steering motion. Because they are provided as a matched pair, the top and bottom cups maintain the relationship intended by Ducati’s designers, reducing the risk of uneven wear or misalignment that can affect handling on the road or track.
Technical specifications
These components carry specific identification and dimensional data used by technicians and parts catalogs. The set is described with the following details to ensure correct match and installation: the top cup is labeled as (TOP) BOC.CANNOTTO 24,5 INF+7,5/SUP+2,5 1199 and the bottom cup as (BOTTOM) BOC.CANNOTTO 24,5 INF+2,5/SUP+7,5 1199. Those codes indicate the bore and offset characteristics that align with the Panigale headstock and bearing arrangement. Retaining the exact spec is essential when replacing worn items or reverting to original geometry after modifications.
Top insert details
The upper component, referred to as BOC.CANNOTTO 24,5 INF+7,5/SUP+2,5 1199, sets the clearance and seating for the upper steering bearing. In practice, this affects preload distribution and the vertical offset between fork clamps and headstock. The numeric notation should be used as a reference during parts ordering and workshop procedures: technicians rely on these markers to confirm compatibility with the Panigale’s steering stem and bearing set. Using the correct top insert reduces the chance of binding or excessive play at the steering pivot.
Bottom insert details
The lower cup marked BOC.CANNOTTO 24,5 INF+2,5/SUP+7,5 1199 complements the top by providing the mating surface for the lower bearing and stabilizing the steering axis under load. Its offset values are deliberately complementary to the upper cup so the combined assembly yields the desired steering geometry. For teams and independent shops, keeping both cups from the same set is important because minor machining and tolerance variations can accumulate; the matched set preserves factory intent and consistency.
Fitment, installation and choice considerations
When installing these inserts, follow accepted service procedures for the Ducati Panigale headstock: remove the steering stem bearings carefully, seat each insert so it sits flush, and torque the assembly according to factory guidance. The note sold as a set emphasizes that both top and bottom cups are included, which simplifies sourcing and minimizes compatibility errors. Choosing parts developed and tested by Ducati Corse means you are using pieces validated against Ducati’s internal requirements, useful for riders seeking race-level dependability or precise replacement parts for street and track use.
Why use Ducati Corse-developed parts
Components developed by Ducati Corse carry the advantage of direct development insight from the manufacturer’s racing arm. That translates into attention to material selection, machining tolerances, and fit that reflect performance priorities. For owners of Ducati Panigale V2 or V4 models, specifying these steering head inserts helps retain the intended handling characteristics and reduces the risk of aftermarket mismatch. In short, these inserts are a practical choice when you want to preserve or restore the steering precision for which the Panigale is known.
